Ionics Instruments 2004 Page 5-3 DLM 30007-08 Rev. A
Table 4. RS-232 Data Output Format
Field # On-Line Sampling Grab Sampling
#1: Sample Mode ONLINE GRAB
#2: Stream Number – –
#3: Sample Number – +
#4: Repetition Number – +
#5: Date (mm/dd/yy) + +
#6: Time (hh:mm 24 hour format) + +
#7: TOC in ppb + +
#8: IC in ppb + +
#9: TC in ppb + +
#10: Acid flow rate (µL/min) + +
#11: Oxidizer flow rate (µL/min) + +
#12: Error message #1 (if any) – –
#13: Error message #2 (if any) – –
#14: TC Transfer Constant + +
#15: IC Transfer Constant + +
#16: TC/IC Offset + +
#17: AC Frequency + +
#18: UV Lamp state + +
– Field not used unless there is an occurrence or set to the proper mode
+ Field used in all occurrences
