Ionics Instruments 2004 Page 4-2 DLM 30007-08 Rev. A
pH paper
(2) Warm Packs (DO NOT OPEN unless returning the analyzer
to Ionics Instruments for repair during cold weather)
Stainless steel Metric tubing converter (1/4 inch to 6mm tube) -
810 and 820 models only
Acid Reagent Cartridge*
Oxidizer Reagent Cartridge*
* Reagents are not installed; they are shipped in a separate box due to shipping regulations.
DO NOT START THE ANALYZER UNTIL THE REAGENTS HAVE BEEN
INSTALLED. Follow the steps outlined in this chapter or in the Maintenance
chapter.
If a major accessory (IC Removal Module, Autosampler, Flow Switch,
Environmental Enclosure or Multistream, etc) has been ordered or shipped
with the analyzer, please refer to their respective documentation for packing
lists, unpacking instructions and installation procedures.
Collecting Additional Equipment
In addition, the following equipment will be needed to complete the installation;
see Appendix B for CE Mark Specifications:
a sampling port equipped with a shut-off valve
a Swagelok adapter (with 1/4" nut and ferrules) from the sampling
port for connection of the 1/4" OD Teflon sample inlet tubing
Open-end wrenches (1/2", 9/16" and 3/4")
Insulated wire (22-12 American Wire Gauge) for analog and alarm
outputs (optional)
a data acquisition system or analog recorder (0–10 V or 4–20 mA)
(optional)
Printer and cable (optional)
IBM-compatible computer (required for Autosampler configuration;
optional for instrument operation in on-line or grab mode)
