EtherCAT®
AG25, AG26 Date: 09.07.2018 Art. No. 88094 Mod. status 225/18 Page 40 of 109
Value
LED
State
Description
0
LED5
Green
Operating voltage applied to control.
No fault
Red,
flashing
Operating voltage applied to control.
Error is active
Off
Operating voltage of control missing
LED6
Off
No function
LED7
Off
No function
LED8
Green
Actuator is within the programmed positioning
window.
Operating voltage of the output stage is applied.
Green,
flashing
Actuator is within the programmed positioning
window.
Operating voltage of the output stage missing.
Red
Actuator is outside the programmed positioning
window.
Operating voltage of the output stage is applied.
Red,
flashing
Actuator is outside the programmed positioning
window.
Operating voltage of the output stage missing.
Off
Operating voltage of control missing
1
LED5
Red
Digital input 1 inactive
Red,
flashing
Error is active
Green
Digital input 1 active:
Off
Operating voltage of control missing
LED6
Red
Digital input 2 inactive
Red,
flashing
Error is active
Green
Digital input 2 active:
Off
Operating voltage of control missing
LED7
Red
Digital input 3 inactive
Red,
flashing
Error is active
Green
Digital input 3 active:
Off
Operating voltage of control missing
LED8
Red
Digital input 4 inactive
Red,
flashing
Error is active
Green
Digital input 4 active:
Off
Operating voltage of control missing
Table 6: Functionality of the system LEDs
