Operation instructions
SIPOS SEVEN: PROFITRON, HiMod
11
Observing
11 Observing
11 Observe
Use the 'Observe' menu to display information
on the actuator:
■
Electronic name plate
■
Inputs and outputs
■
Actuator status
The illustration on the right shows the structure
of the ‘Observe’ menu.
Parameters cannot be change in the 'Observe'
menu.
Navigation through the menu “Observe” is identi-
cal to the other menus, refer also to „4.4 Naviga-
tion through the menus“ on page 23.
11�1 Electronic name plate
11�1�1 Tag number
The tag number is displayed here.
The tag number is entered in the ‘Special pa-
rameters’ menu, refer to „8.6.1 Tag number“ on
page 84.
11�1�2 Order number and equipment
If “Equipment” is selected in the “Order number
and equipment” menu, a list with all characteris-
tics of the actuator appears.
The overview is generated by decoding the
order number.
11�1�3 Serial number
The 13-digit number of the current electron-
ics unit is displayed. If the electronics unit is
replaced, the serial number of the ‘former’
electronics unit can be found under the ’Original
serial number’ menu item.
11�1�4 Original serial number
Here, the number of the originally supplied
electronics unit is displayed (only relevant when
exchanging the electronics unit). When deliver-
ing an actuator, serial number and original serial
number are identical. If the electronics unit is
replacedonceagain,therstnumberremains
identical.
1
2SQ7 only.
2
Differentindicationdependingontheeld-
bus:
- PROFIBUS
- Modbus
- HART
3
Depending on the additional gear
the following is displayed:
- Speed for rotary gearbox
- Positioning time for part-turn gearbox
- Positioning speed for linear thrust unit
- Tripping torque for rotary and
part-turn gearboxes
- Tripping force for linear thrust unit.
4
Actuator with niP only.
Fig�: Observe menu
Electronic name plate
Observing
Inputs and outputs
Actuator status
Setpoint for positioner/proc. contr.
Intermediate contact
Process actual value (proc. contr.)
Actual value
Torque (torque meas..)
Motor warranty
DC link voltage XXX V
Tripping torque
3
reached
Fieldbus communication
2
Binary outputs
Motor temperature
Electronics temperature
Current speed
3
Analog input and outputs
Torque switch
1
Binary inputs
Stroke
4
Motor current X,X A
Firmware version
HART
Serial number
Bluetooth FCC-ID
Tag number
Original serial number
Bluetooth IC-ID
Order number and equipment
Bluetooth MAC address
