SIPOS SEVEN 2SA7 - Firmware Version; Inputs and Outputs (Observe); Binary Inputs; Analog Input and Outputs

Operation instructions
SIPOS SEVEN: PROFITRON, HiMod
Page 102 Y070.302/EN
11 Observing
11
Observing
11�2 Inputs and outputs (observe)
11�2�1 Binary inputs
Display of the voltage level applied (low oder high):
■
Binary input CLOSE,
■
Binary input OPEN,
■
Binary input STOP,
■
Binary input EMERGENCY and
■
Binary input MODE
Refer also to chapter „8.3.5 Control system – Binary input“ on page 70 and chapter „8.4.1
EMERGENCY input“ on page 77.
Binary outputs
The voltage level issued via signaling outputs 1 – 8 (low or high) is indicated here. Refer also to
„8.3.9 Control system– Binary outputs“ on page 71.
11�2�2 Analog input and outputs
The currently measured currents at analog inputs AI1 and AI2 as well as the currents supplied at
analog outputs AO1 and AO2 can be viewed here.
Analog input AI2 and analog output AO2 are only displayed if the HART module or the additional
analog sub-assembly are available.
Refer also to „8.3.10 Control system – Analog output AO1“ on page 73 and „8.3.11 Control
system – Analog output AO2“ on page 74.
11�2�3 Torque switch (2SQ7 only)
Here, it will be indicated whether the torque switches in CLOSE direction and OPEN direction are
active.
11�2�4 Fieldbus communication
PROFIBUS DP
Displayed for available PROFIBUS interface:
■
Active channel
– Channel 1 active
– Channel 2 active
– No channel active
■
Baud rate:
– No data exchange
– 9.6 kbit/s – 1.5 mbit/s; e.g. Baud 187.5 kbit/s
■
Status:
– WaitPrm(noeldbusparameterization)
– WaitCfg(noeldbusconguration)
– Data Exchange (cyclic data exchange)
11�1�5 Firmware version
Version number and issue number is displayed,
see illustration on the right.
Version number
3.03 2016. 01.11
Version
number
Year Month Day
Fig.: Example of rmware version number
