SIPOS SEVEN 2SA7 - Proportional Move

Y070.302/EN Page 81
Operation instructions
SIPOS SEVEN: PROFITRON, HiMod
8
Parameters and possible parameter values
8 Parameters and possible parameter values
8�5 Software functions
8�5�3 Proportional move
Even for very short control times, the actuator is operated proportionally to the length of the control
time.
The entire positioning time (run time from end position to end position) has to be determined to this
end. The time can either be automatically determined by the actuator after end position adjustment
ormeasuredanddenedbytheuser.
Refer also to „Binary control mode“ on page 68.
Duration
Autom� determination
Automatic determination of the run time.
User dened
Durationisdenedbytheuser.
Duration OPEN
Duration CLOSE
The duration (run time) will automatically be determined after any end position adjustment or
changes in the ramp-up time. For determining the duration, the actuator must be operated into
one direction for at least 3 % of the travel.
Duration OPEN
Duration CLOSE
IndividualdurationsforOPENandCLOSEcanbespecied.
Possible setting for the positioning time: 5 to 3,276 s.
Default setting is 60.
Proportional move
Duration
Autom. determination
Userdened
Duration
Autom. determination
Userdened
Autom� determination
Duration OPEN X.X s
Duration CLOSE X.X s
User dened
Duration OPEN X.X s
Duration CLOSE X.X s
