SIPOS SEVEN 2SA7 - Lubrication Intervals and Lubricants; Lubricant Assignment and Quantity

Operation instructions
SIPOS SEVEN: PROFITRON, HiMod
Page 112 Y070.302/EN
14 Maintenance, inspection, service
14
Maintenance, inspection, service
14�2 Lubrication intervals and lubricants
Lubrication intervals
Perform service or inspection after approx� 8 years (refer to previous chapter 14.1).
After 50 operating hours or 1 year, regrease coupling shaft A, if available, at the greasing nipple.
For output shaft form A, ensure that the valve stem is greased separately!
These intervals are valid for normal load. When exposed to more intensive loads, the maintenance
intervals are reduced accordingly.
Actuators in high temperature version – add. version T09 – have to be checked for proper condition
by the SIPOS service every 2 years and wear parts have to be replaced!
Whenever the covers and hoods are removed, the seals must be inspected for damage. Replace
and regrease if necessary.
14�3 Lubricant assignment and quantity
Actuator type
2SA7�1/2 2SA7�3/4 2SA7�5/6/7/8
Gear oil Lubricant
quantity
760 cm
3
1600 cm
3
2400 cm
3
Filling level
1
max. 46 mm max. 58 mm 23 – 27 mm
Lubricant
2
Klübersynth GH 6 – 220 N (by Klüber)
3
or Alphasyn PG 220 Polyglycol (by Castrol),
Berusynth EP 220 (by Bechem),
Panolin EP gear synth 220 (by Kleenoil).
Mobil SHC
Gear 220
3,
Other lubrication
points
4
Lubricant
quantity
50 cm
3
Lubricant
2
Lubrication grease AR1 (ZEPF)
Output shaft form A
5
(2SA7)
Lubricant
quantity
2 cm
3
Lubricant
2
Commercial ball bearing grease
2SG7... part-turn actuator
2SQ7... part-turn actuator
virtually maintenance-free.
■
The manufacturer's instructions and relevant regulations are to be observed when handling and
disposing of lubricants. Technical information concerning lubricants is available on request.
■
Beforeusinganewalternativelubricant(otherthanthelubricantlledinthefactory),thegear
units and gear parts have to be rinsed and cleaned (avoid mixing the oils).
___________________________
*
1
Measuredfromthelubricantsurfacetotheexternalwallofthehousingatoilllingscrew.
*
2
Ambient temperature range -20 – +70 °C.
*
3
Lubricant used in the factory.
*
4
E.g. sealing rings, gear systems, bearings, feather keys, uncoated surface etc.
*
5
If applicable.
