Ski-Doo 2005 SUMMIT HIGHMARK - Section 04 ENGINE MANAGEMENT (SDI); Subsection 01 (OVERVIEW)

Section 04 ENGINE MANAGEMENT (SDI)
Subsection 01 (OVERVIEW)
OVERVIEW
+ -
A35C3RS
BATTERY
ECM
IN OUT
Ignition
coil
RAVE
system
FR
FI
CPS
CTS
TPS
ATS
APS
KS
LEGEND
APS 
ATS 
CPS 
ECM 
FI 
FR 
KS 
TPS 
CTS 
Air pressure sensor
Air temperature sensor
Crankshaft position sensor
Engine control module
Fuel injector
Fuel rail
Knock sensor
Throttle position sensor
Coolant temperature sensor
Capacitor
Fuel pump
E-RAVE
actuator
mmr2005-124 117
