Section 07 REAR SUSPENSION
Subsection 01 (SC SUSPENSION)
A33F5WA
TYPICAL — REMOVE SUSPENSION
SUSPENSION INSTALLATION
Installation is the reverse of removal procedure.
Pay attention to the following details.
Inspect track thoroughly before reinstalling sus-
pension. Refer to TRACK.
Install suspension into track with front portion
first.
Adjust track tension.
RIDE ADJUSTMENT
Refer to the appropriate Operator’sGuide.
LUBRICATION
Lubricate front and rear arms at grease fittings
using suspension synthetic grease (P/N 293 550
033).
