Section02ENGINE
Subsection 04 (ENGINE REMOVAL AND INSTALLATION)
A35C29A
4
1
2
3
3
2
3
ENGINE SUPPORTS
1. LH support
2. RH supports
3. Rubber mounts
4. Engine stopper
INSTALLATION
To install engine in vehicle, reverse the removal
procedure. However, pay attention to the follow-
ing.
PTO Engine Support
Lower engine as close as possible to its original
position.
First, position PTO engine support on engine and
insert front tab of PTO engine support on rubber
mount.
A35C2BA
1
2
INSERT FRONT TAB FIRST
1. Front tab
2. PTO engine support
Secure PTO engine support.
A35C2CA
2
1
1. Secure
2. PTO engine support
Using a pry bar, position rear tab of PTO engine
support in place on rubber mount.
32 mmr2005-115
