Section02ENGINE
Subsection 07 (TOP END)
Scrape off carbon formation from cylinder block
exhaust port, cylinder head and piston dome.
NOTE: The letters “AorB” (besideanarrowon
the piston dome) must be visible after cleaning.
Clean the piston ring groove with a groove cleaner
tool or with a piece of broken ring.
INSPECTION
NOTE: For dimension measurement procedures,
refer to ENGINE MEASUREMENT.
Reed Valve
There must not be any play between any blade
and valve body when exerting a finger pressure
on blade. Inspect adapter condition.
A35C12A
Ifaplayisfelt,replacereedvalve.
Check the rubber flange for cracks and/or damage.
Decompressor
Mach Z
Inspect holes for carbon deposits and if clogged,
remove decompressor plug to allow proper clean-
ing.
A35C0WA
A35C0XA
A35C0YA
mmr2005-117 55
