Ski-Doo 2005 SUMMIT HIGHMARK - Page 203

Section 06 DRIVE SYSTEM
Subsection 02 (DRIVE PULLEY)
TRA V
NOTE: This is a lubrication free drive pulley. Always refer to appropriate parts catalog for replacement
parts. Most parts of TRA V are not interchangeable with other TRA models.
A35D0VS
4
53 Nm
(39 lbfft)
Loctite 609
10 Nm
(89 lbfin)
8
14
21
13
12
10
15
Starter electric models
Loctite
271
5
6
1
3
2
88 Nm
(65 lbfft)
Loctite 609
9
9
20
7
22
23
24
27
26
28
25 Nm
(18 lbfft)
11
Loctite 609
Loctite
609
30
16
17
19
10 Nm
(89 lbfin)
29
18
10 Nm
(89 lbfin)
190 mmr2005-132
