Section 06 DRIVE SYSTEM
Subsection 03 (DRIVEN PULLEY)
A18C0AA
3 2
1
4
5
6
A
C
B
LETTERS AND NUMBERS SHOWN IN ILLUSTRATION ARE
ACTUAL LETTERS AND NUMBERS EMBOSSED ON PARTS
NOTE: Always recheck torsional preload after ad-
justing.
Pulley Alignment and Drive Belt Height
Refer to PULLEY ALIGNMENT and DRIVE BELT to
perform adjustments.
CAUTION: Drive belt and pulley adjustments
must always be checked whenever pulleys
have been removed, replaced or disassem-
bled.
212 mmr2005-133
