Section10TECHNICALDATA
Subsection 01 (MACH Z/SUMMIT 1000 SDI)
MACH Z SUMMIT
MODEL
1000 SDI 1000 SDI
Starter solenoid A
30
Fuse
Fuel level sensor A 0.25 N.A.
FUEL SYSTEM
Throttle body type Dell'Orto
Idle speed ± 200 RPM
1600
Gas type Premium unleaded
Inside North America (R+M)/2
91
Pump octane number
Outside North America RON 95
Gas/oil ratio Injection
Injection oil XP-S 2-stroke synthetic blend
COOLING SYSTEM
Type Liquid
Ethyl glycol/water mix (50% coolant,
50% distilled water).
Mixture
Use coolant specifically designed for
aluminum engines.
Coolant
Premixed P/N 219 700 362 — 12 x 1 L
Thermostat opening temperature
°C(°F)
N.A.
Radiator cap opening pressure kPa (PSI) 90 (13)
DRIVE
Chaincase oil XP-S Synthetic chaincase oil
Chain drive ratio 29/49
21/49
EUR: 23/49
Pitch in 3/8
Chain
Type/links qty/plate qty Silent 82/13 Silent 86/13
Drive pulley type TRA V
Clutch engagement ± 100 RPM
3400
3500
EUR: 3400
Spring color Green/Purple
Pink/White
EUR: Green/White
Spring length mm (in) 130.2 (5.126)
124.5 (4.90)
EUR: 110.7 (4.36)
Pin (with roller (P/N 417 222 762)) Steel solid (P/N 417 004 309)
Ramp 434
433
EUR: 600
Drive pulley calibration
Screw position 6
4
EUR: 3
Type HPV Roller HPV VSA
Spring preload 0.0Driven pulley type
Cam angle 44°/33° 44°/30°
Pulley distance Z
mm (in)
27.5 (1.083)
X
mm (in)
37.0 ± 0.5 (1.457 ± 0.2)
Offset
Y – X
mm (in)
1.23 (.0484)
318 mmr2005-145
