Section02ENGINE
Subsection 07 (TOP END)
A35C16A
5 1
3 7
6 4
2 8
Install cylinder head and torque screws following
this sequence.
A35C15A
10 4 6 8
7 5 3 9
1 2 1112
LH and RH side intake adapters are different. In-
stall as shown.
A35C14A
Properly seat adapters against engine flanges and
torque screws no. 1 in a criss-cross sequence.
mmr2005-117 59
