178 • Parameters List
_____________________________________________________________________________________________
Parameter Default setting Range Set 1 Set 2 Set 3 Set 4
Range w/dip switch #7=ON
STOP PARAMETERS Refer to section 7.8.4 page 67
SOFT STOP CURVE 1 (STANDARD)
0 (BASIC) = Basic
1 (STANDARD)= Standard Curve
2!! = Pump Control Curve # 1
3!! = Pump Control Curve # 2
4!! = Pump Control Curve # 3
5 (TORQUE) = Torque Control
STOP TACHO. GAIN
When setting Dip sw # 2
On for Tacho Mode,
Note: Tacho Feedback
functions in its basic form.
Additional curves except
for the basic Linear curve
are optional. Consult the
factory for correct tacho
selection and mechanical
installation.
0 (MIN. GAIN) 0 (MIN. GAIN)= Minimum gain tacho
control
1!! = Second level tacho gain
2!! = Third level tacho gain
3!! = Fourth level tacho gain
4!! = Fifth level tacho gain
5!! = Sixth level tacho gain
DEC. TIME 0 SEC. 0-30 SEC.
0-90 SEC.
FINAL TORQUE 0 (MIN) 0 (MIN.)– 10 (MAX.)
COAST DOWN DELAY OFF OFF, 10-3600 SEC.
DUAL ADJUSTMENT
PARAMETERS
Refer to section 7.8.5 page 70
DA: INIT. VOLT
or DA: INIT. CURRENT
30%
or 100%
10-50% of Vn
or 100-400% of motor FLA
5-80% of Vn
or 100-400% of motor FLA
DA: CUR. LIMIT 400% OF FLA 100-400% of motor FLA.
100-700% of motor FLA. With the
maximum limitation of:
440x(FLC/FLA)
DA: ACC. TIME 10 SEC. 1-30 SEC.
1-90 SEC.
DA: DEC. TIME 0 SEC. 0-30 SEC.
0-90 SEC.
DA: MOTOR FLA 150 AMP 33-100% of STARTER FLC
FAULT PARAMETERS Refer to section 7.8.6 page 71
UV & PL AUTO RST NO YES/NO
UNDER CUR. RESET
OFF 10-120 MIN. / OFF
BYPASS OPEN TRIP
ENABLE ENABLE / DISABLE
TRIP AFTER BYPAS
ENABLE ENABLE / DISABLE
BY-PASS AUTO RST NO YES/NO
SET CURVE 0 FLT ENABLE ENABLE / DISABLE
PWR ON & NO STRT ENABLE ENABLE / DISABLE
INSULATION ALARM OFF OFF/ 0.2-20Mohm
INSULATION TRIP OFF OFF/ 0.2-20Mohm
PHASE SEQUENCE POSITIVE POSITIVE/NEGATIVE/IGNORE
I/O PROGRAMMING
PARAMETERS
Refer to section 7.8.7 page 73
PROG. INPUT #7 RESET TEST/ RESET/MULTI SOFT STOP
(MULTI SOFT STOP with optional
software only)
PROG. INPUT #8 DUAL ADJUSTMENT DUAL ADJUSTMENT/RESET
FAULT RELAY TYPE
FAULT FAULT/FAULT – FAIL SAFE
IMM. RELAY TYPE IMMEDIATE IMMEDIATE/# STRTS PREALRM
RELAY ON DELAY 0 SEC. 0.0-3600 SEC.
RELAY OFF DELAY 0 SEC. 0.0-3600 SEC.
ANALOG OUTPUT RELATIVE CURRENT RELATIVE CURRENT/RELATIVE
POWER
COMM. PARAMETERS
MODBUS
Refer to section 7.8.8 page 75
COMM. PROTOCOL MODBUS MODBUS/PROFIBUS/DEVICENET
BAUD RATE 19200(MODBUS) 1200/2400/4800/9600/19200
PARITY CHECK EVEN EVEN/ODD/NO
SERIAL LINK NO. OFF OFF/1-247
