181 • General Information:
_______________________________________________________________________________________________
External fault 1 ..........................Trips when an external contact closes for 2 sec.
External fault 2 ..........................Trips when an external contact closes for 2 sec.
Unbalance Current. ...................Trips when Current Unbalance exceeds preset value for more than
“Unbalance delay”
Ground Fault Current.................Trips when Ground Fault Current exceeds preset level for more than “Gnd
Fault Delay”
Power ON & No Start**** ...........Trips when three phases voltage is connected to the soft-starter input and
start signal was not issued for more than 30 seconds.
By-Pass Open **** .....................Trips if the Bypass Contactor and one or two if its phases did not close.
* Special settings, extended range
** With optional Auto Reset
*** Future enhancement
**** Can be disable
Control:
Displays .....................................LCD in 4 – Field selectable languages and 8 LEDs
Keypad ......................................6 keys for easy setting
Aux. Contact – Immediate .........1 C/O, 8A, 250VAC, 2000VA
Aux. Contact – End of Acceleration..1 C/O, 8A, 250VAC, 2000VA
Fault Contact .............................1 C/O, 8A, 250VAC, 2000VA
Communication .........................RS 485 with MODBUS or PROFIBUS or DeviceNet protocols
Temperatures
...........................Operating -10˚ to 50˚C
Storage -20˚ to 70˚C
Enclosure:
Degree of Protection..................IP 00 - Chassis type
IP 32 - Standard
IP 54 – Optional
Paint ..........................................RAL 7032 – standard
Other colors - optional
Normal Service Conditions:
Altitude ......................................Should not exceed 1000m.
Consult the factory for equipment to be used at higher altitudes.
Humidity ....................................95% Non condensed
Starter Consumption Ratings (for IP00 OEM Kit)
Peak consumption .....................350VA during start process and less than 20 VA otherwise
Solcon Industries Ltd.
www.solcon.com Technical support: office@solcon.com
