183
Color Background
Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
the Mix Ptn Select menu (standard wipe patterns 1 to
24), and you can then adjust the following parameters.
3 To adjust color 1, set [Color 1] on, and to adjust color
2 set [Color 2] on, then adjust the parameters.
4 If required, set the pattern modifiers.
When turning [Position] on and setting the pattern
position
a) See page 130.
When turning [Multi] on and using replications of
the same pattern
a) See page 132.
When turning [Aspect] on and setting the aspect
ratio of the pattern
a) See page 132.
When turning [Pairing] on and making a wipe
pattern like a Venetian blind
When turning [Angle] on in the <Rotation> group
and slanting the pattern
a) See page 131.
When turning [Speed] on in the <Rotation> group
and rotating the pattern at a constant rate
a) See page 131.
When selecting H (horizontal) or V (vertical) in the
<Modulation> group and applying waviness to the
pattern
(The modulation is always a sine wave.)
When using 1080PsF mode in an HD system, the
modulation function is not available.
a) See “Applying modulation to the wipe pattern (Modulation)” (page
133).
5 To interchange color 1 and color 2, press the [Color
Invert] button, turning it on.
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal
position
–200.00 to
+200.00
a)
2 Position V Vertical position –200.00 to
+200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of
repetitions of
pattern
horizontally
1 to 63
2 V Multi Number of
repetitions of
pattern vertically
1 to 63
3 Invert Type Replication
layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio –100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
1 Width Width of the slits 1 to 128
(integer)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern
rotation
–100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of
pattern
–100.00 to
+100.00
a)
Notes
Knob Parameter Adjustment Setting values
1 Amplitude Amplitude of
modulation
0.00 to 100.00
2 Frequency Frequency of
modulation
0.00 to 100.00
3 Speed Speed of waves –100.00 to
+100.00
a)
