Basic Operation 2-1
2 Basic Operation
2.1 The control Panel
The 320x240-dot touch screen has a unique interface system that provides detailed status
information and offers a more flexible and powerful control of the printer’s configuration.
All screen and optional panel controls on the touch screen are easily formatted to allow
quick access to the most common cutter settings. Next to the status messages and/or menu
options displayed on the touch screen, button symbols can be pressed to change menu
items or to change the value for a given submenu/parameter.
The most used functions are explained in the following paragraphs. It is advised not to
touch the control panel while the machine is printing or cutting, except when canceling the
current job.
FIG 2-1
2-1 DC5(sx) TOUCH SCREEN
There is also screen saving feature. After a certain amount of time the screen goes blank and
this logo appears on the screen. Touching the screen once disables the screen saver.
FIG 2-2
2-2 SCREEN SAVER
