DC5 User’s Manual
Detailed Operation 4-6
4.3 Cutter menu
This menu bundles all the cutter settings of the DC5(sx). All settings in this section are user-
dependent (information is contained within each of the sixteen individual user settings, see
section 2.1.4.).
4.3.1 Knife pressure
The knife pressure submenu is used to change the default knife pressure (same as in section
2.4 but it can be changed when no media is loaded, however it can’t be tested). The knife
pressure can be set between 0 and 400 grams.
Press the Knife pressure button, change the knife pressure to the desired knife pressure.
Press to confirm or to cancel.
4.3.2 Knife offset
The knife offset is explained in section 2.4.
4.3.3 Velocity
The Velocity submenu is used to change the default velocity for the knife. The velocity can
be set between 50 mm/s (2 ips) and 600 mm/s (24 ips). The default velocity is 500 mm/s (20
ips). Press the Velocity button, press on the desired velocity to change the velocity, use the
arrow up/down if the desired velocity is not on the screen.
Press to confirm or
to cancel.
4.3.4 Overcut
Use the overcut submenu to generate an overcut in order to facilitate weeding the cut. Each
time the knife goes up or down, the cutter cuts a bit further then it should. The overcut
setting can be disabled (=0) or set to any value between 0 and 1mm in increments of
0.1mm. Press the overcut button and change to the desired value.
Press to confirm or
to cancel.
