DC5 User’s Manual
Detailed Operation 4-12
4.5 Communication
4.5.1 DHCP
DHCP can be set to on or off, it is recommended to work with a fixed IP address (DHCP off).
Section 1.5.2 explains how to set this parameter.
4.5.2 Configure
This sub menu is used to set the IP address parameters. Section 1.5.2 explains how.
4.5.3 Status
This sub menu gives an overview of the IP address settings, whether they are set manually
or filled in by the DHCP server. It also shows the MAC address of the Ethernet connection.
4.5.4 USB Class
USB class can be set to Summa USB port 1, Summa USB port 2, Summa USB port 3 or
Summa USB port 4.
Because of the different USB id’s, the computer can make a distinction between several
printers attached to it (maximum 4).
Press the USB Class button, set it to the desired USB Class.
Press to confirm or to cancel. The default mode is Summa USB port 1.
4.6 Shut down….
After pressing the shut down button, the DC5(sx) removes any cassette from the carriage,
closes any open files on the hard disk and raises the pinch rollers. It is advised to use this key
when shutting down the DC5(sx), especially for minimizing wear on the pinch rollers. If the
pinch rollers are left down for a long period of time, a flat spot is created on the wheel and
tracking becomes a problem and is not guaranteed any more. The pinch rollers are
automatically raised when the DC5(sx) is idle for more than 4 minutes.
4.7 Reset
When pressing the reset button, the DC5(sx) will reset. This reset is not a full reset. To
completely reset the machine, perform a cold reset (switch off and on the power to the
machine).
The USB id in the printing software has to be the same as the chosen USB
id in the DC5(sx). Each time a new USB is selected on the printer and connected
for the first time to the computer, the wizard for installing a driver will be started
