DC5 User’s Manual
Print&Cut 3-6
3.2 Cutting trough
The cutting through functionality is focussed to cut simple shapes (e.g. rectangles). It is
most used in combination with contour cutting.
An interrupted cutting line makes sure that the material remains together thanks to the
small media ‘bridges’. When the job is finished the cut pieces can be torn loose.
FIG 3-7
3-7 FLEXCUT PRINCIPLE
Some software can recognize the difference between a contour line and a cut-through line.
The software then first sends the data of the contour lines to the cutter, activates FlexCut,
panelling mode and vector sorting and sends the data for cutting-through to the cutter.
Setting the parameters for cutting through the media:
1. Power on the printer and load the media (see section 1.6.1).
Settings | Cutter menu | FlexCut
Full pressure 180 gr
Back
Home
Full pressure cut length 7.500 mm
Flex pressure 80gr
Flex pressure cut length 0.750 mm
