DC5 User’s Manual
Detailed Operation 4-11
4.4.8 Coil setup
This test is used to set the knife to “landing.” The cut quality is seriously affected by
incorrect landing setting. Before changing these values, write them down, as there is no
default setting for these parameters. After adjustment, the value is saved automatically
when leaving the sub menu. The landing determines, among other things, the force at
which the tool hits the media. When calibrating the landing, the tool holder with the knife
must be inserted in the head. Be sure that the knife does not protrude.
Use to lower the landing value until the tool is in the “up” position. Then use
to raise the value of the parameter. With each unit of change, continue checking
if the tool is completely down yet. Once the tool is completely down, raise the value five
units, which becomes then the proper setting.
Press to leave the menu.
4.4.9 Calibrate NTC
This test is used when a printhead is replaced. This test is fully automatic. The machine
needs to be rebooted after the test.
Do not calibrate NTC’s unless instructed by a certified technician. Wait at
least half an hour after the last printed job before performing a calibration (the
