DC5 User’s Manual
Print&Cut 3-7
Press arrows or use
Numpad to change the Full
pressure and press Apply to
confirm.
180 gr is a recommended
starting value for the full (cut
through) pressure.
Press arrows or use
Numpad to change the Full
pressure cut length and
press Apply to confirm.
10 mm is a recommended
starting value for the cutting
length at full pressure.
Press arrows or use
Numpad to change the Flex
pressure and press Apply to
confirm.
50% of the full pressure is a
recommended starting value
for the flex (bridge) pressure.
Press arrows or use
Numpad to change the Flex
pressure cut length and
press Test to confirm and
cut out the test.
1mm is a recommended
starting value for the cutting
length at flex pressure.
The cutter will cut out a test pattern.
Check if the result is satisfactory. If not, change one of the 4 parameters above. Reducing
the velocity can also improve the result. It is never recommended to use cutting speeds
larger than 400mm/s (16 ips) with cutting pressures above 200 gr.
enough, making sure the pieces can be taken out easily, and not cutting too
deep making sure the material keeps it strength while cutting. Sometimes this
balance doesn’t exist, which means this material can’t be cut through with
When cutting through it is recommended that parallel lines are at least 1
cm away from each other. Otherwise, while cutting the second line, the first line
