Specifications 6-1
6 SPECIFICATIONS
The S Class 3™ range of cutters has been designed to produce computer-generated graphic
designs on cut sheet or roll vinyl media. Using the integrated optical positioning system (OPOS
X) allows contour cutting of printed sheets of material. By replacing the knife with a pen, these
cutters can also be used to produce inexpensive previews of new graphic designs on paper.
The S Class 3™ series are available in different sizes and different configurations. Depending on
the region, certain sizes and or configurations may not be available. Also branding may be
different. In this section we refer to the basic model names S3 75, S3 120, S3 140 and S3 160.
Where known, it is marked if a specification is configuration depended.
• Drag head (model name extension: ‘D’ e.g. S3D75), Tangential head (model name
extension: ‘T’ e.g. S3T75) or PRO CAM head (model name extension: ‘TC’ e.g. S3TC75).
• Integrated roll feed system with media flanges.
• Fully adjustable media widths.
• Stand with basket.
• Cutting strip.
• Strip for extra tool (only to be used on model names with extension ‘TC’).
• Pressure on outer pinch rollers can be reduced.
• Extra pinch rollers upgradable in the field.
• Separate cut off knife.
• One front and two back media sensors for media detection.
• Integrated OPOS positioning and alignment system.
• or white light sensor automatically raised and lowered with barcode recognition and
OPOS X[n]-line detection on model names with extension ‘D’ or ‘T’.
• or integrated camera with barcode recognition and OPOS X[n]-line detection on model
names with extension ‘TC’.
• USB memory stick slot.
• USB, Ethernet and WiFi communication interfaces.
• Integrated SMARC module on model names with extension ‘TC’.
