S Class 3 User’s Manual

OPOS 3-9

NOTE: Use easy reference points for quick positioning of the sheet. In the figure

below, an edge of the base plate and the side of the pinch roller assembly are

used to align the sheets.

FIG 3-4

3-4 POSITIONING THE MEDIA FOR MULTIPLE SHEETS
