Summa S3 Series - Pinch Roller Lever

S Class 3 User’s Manual
Setup 1-25
10. Raise the pinch roller lever to press the media firmly against the grit rollers. After one second the
tool carriage automatically moves from the right to the left to sense the usable media width.
FIG 1-18
1-18 PINCH ROLLER LEVER
ATTENTION: We do not recommend unrolling the media manually from the roll.
The cutter automatically unrolls the media during the load sequence.
11. The positioning and routing of sheet material is identical to that of roll media.
12. The cutter is now operational.
