S Class 3 User’s Manual
Setup 1-31
The S Class 3 cutters can also function as a pen plotter when a pen is installed.
1. Loosen the head clamp screw and remove the tool from the clamp.
2. Install the pen in the clamp and tighten the clamp screw.
3. You can change the tool on the touch panel, in Summa Cutter Control (PC only) or in the cutting
software.
Changing to the pen tool disables the knife offset correction and changes the pressure to pen
pressure.
ATTENTION: The information on the touchscreen shows the currently selected
tool by the cutter. Make sure the cutter’s tool setting matches the actual tool in
use.
