S Class 3 User’s Manual
Setup 1-26
➢ Changing origin.
1. Power on the cutter and load the media (see section 1.5).
2. Tap .
3. Use the arrows to change
the origin. The value next
to Y is the width that is left.
4. Tap to confirm the new
origin.
➢ Load wider.
The function Load wider makes it possible to redefine the limits of the Y-axis so that the cutter can
cut outside the pinch rollers.
1. Power on the cutter and load the media (see section 1.5).
2. Tap .
3. Tap Actions.
4. Tap Load wider.
5. Set the origin with the
arrows and tap to
confirm.
6. Set the size with the
arrows and tap to
confirm.
ATTENTION: Accurate tracking is not guaranteed when using this mode.
Configuration 1
LAN 192.168.10.2
Knife pressureSet origin
Set origin
Configuration 1
LAN 192.168.10.2
Menu
Actions
Knife pressureSet origin
Set width
