S Class 3 User’s Manual
Specifications 6-8
USB series “B” receptacle (female plug)
USB series “B” plug (male plug)
FAT32, max 16GB and max 100 files per folder.
Only cut files (DMPL and HPGL files with
extension .plt, .dmpl or .hpgl) or firmware files
(files with extension .summa1).
(1)
Wi-Fi only available in Europe, US and Canada due to EMC tests done only according to European Directive
(2014/53/EU) and according to USA & CANADA standards.
Table 6-8 S CLASS 3 INTERFACE SPECIFICATIONS
DM/PL, HP-GL (758x emulation), HP-GL/2
Confidence test, DIN test
Table 6-9 S CLASS 3 FIRMWARE
(Cutter without media)
35 - 75 %, non-condensing
Table 6-10 S CLASS 3 ENVIRONMENTAL SPECIFICATIONS
IMPORTANT: The use of dimensionally stable media is an essential pre-requisite
to obtain high cut quality. Additionally, media expansion or contraction may occur
as a result of temperature variations. To improve the dimensional stability of
media, let it stabilize to the current environmental conditions before use, for a
minimum period of 24 hours.
