S Class 3 User’s Manual
Detailed operation 4-11
This submenu allows setting all user parameters to the factory settings.
This submenu allows changing the unrolling procedure for vinyl. When this function is
activated, the cutter will unroll the vinyl automatically when required. If this function is
deactivated, you need to manually unroll enough media before you start cutting. Autoload is
activated by default. You can also set Autoload to Ask. In this case, the cutter does not
automatically start loading vinyl after it was switched on or after the pinch rollers were
lowered; a message appears on the touchscreen to adjust the pressure of the pinch rollers.
This submenu allows setting or changing the distance between the jobs when performing
multiple recuts. The default value is 40 mm.
The media sensors detect whether media is loaded and detect the end of the media. They
prevent damage to the cutting strip and knife tip. This submenu allows activating or
deactivating the sensors. When the sensors are activated, the cutter searches for the front end
of the media during the loading procedure. If it does not find it after moving the media
backwards for 1 m (+/- 3 feet), it stops returning the media and sets the origin in the X-axis.
The cutter will also stop during the loading procedure or while it is cutting if the rear sensor
detects the end of the media. The cutter does not search for the front end of the media and
assumes that the loaded media is endless if the sensors are not activated.
This submenu is only available on roll cutters with a roll-up motor.
