1K-3 Charging System:
Component Location
Charging System Components Location
Z9J0111B03001
Refer to “Engine Control System Components / Engine Electrical Device Location” in Section 1A (Page 1A-15).
Diagnostic Information and Procedures
Charging System Diagnosis
Z9J0111B04001
Condition Possible cause Correction / Reference Item
Alternator (Battery charge
coil) does not charge.
Open or short circuit lead wires. Repair or replace.
Open or short circuit battery charge coil. Replace.
Rectifier/Regulator failure. Replace.
Main fuse blown out. Replace.
Poor or broken battery connection. Repair or Replace.
Alternator (Battery charge
coil) overcharge.
Rectifier/Regulator failure. Replace.
Poorly grounded rectifier/regulator. Repair or Retighten.
Unstable charging Short circuit battery charge coil. Replace.
Loose lead wire connection. Repair or replace.
Rectifier/regulator failure. Replace.
Poor or broken battery connection. Repair or replace.
