Suzuki DF70A - Page 337

Fuel / Water Hose Routing: 4B-4
1
2
3
5
4
I9J011420004-01
1. Fuel hose / protector (Joint to low pressure fuel filter) 3. Fuel hose (Fuel pump to fuel vapor separator) 5. Low pressure fuel filter
2. Fuel hose (Fuel filter to fuel pump) 4. Low pressure fuel pump
