1A-12 Engine General Information and Diagnosis:
Fail-Safe System Description
Z9J0111101005
The fail-safe system is closely related to the self-diagnostic system.
When an abnormality occurs in a sensor signal, the ECM ignores the out-of-range signal and assumes a pre-
programmed value for the failed sensors.
This allows the engine to continue running under the fail-safe condition.
Pre-Programmed Value for Fail-Safe System
NOTE
There is no back-up system for the ECM itself. The engine will stop if it has failed.
Neutral switch
While the shift sensor outputs a forward or reverse signal, the ECM
receives a neutral signal from the neutral switch.
Rectifier/Regulator
(Over-charging)
Receiving 16 volts or higher signal.
Oil pressure switch
While the engine is stopped and the ignition switch is on, the ECM receives
an “off” signal from the oil pressure switch.
Trim sensor Receiving an out of range “0.2 – 4.8 V” signal.
Failed Item Condition
Failed Item Pre-Programmed Value
MAP sensor 1 150 – 758 mmHg / (5.9 – 30 inHg.)
(The value will change according to the current engine speed.)
Air intake system The control is executed with the maximum engine speed of 2 000 r/min.
Cylinder temp. sensor 60 °C (140 °F)
IAT sensor 45 °C (113 °F)
Exhaust manifold temp. sensor 60 °C (140 °F)
Throttle position sensor The control is executed with the throttle opening at 5 degrees.
Shift position sensor The shift position (Fwd / Neu / Rev) is detected with the neutral switch signal.
Trim sensor The control is continued with fixed sensor output as 3.5 V.
