SV 977D User Manual - Appendixes
Word
number
Name
Comment
...
[ResSpec[..]]
results of the spectrum measurement:
– results are available if the spectra recording during measurement
is enabled (see the word "SpecLogg" in the measurement parameter
block – see
Table B.7)
– results are in format 0,01 dB
Table B.28. Block of user marker (only one word)
Word
number
Name
Comment
0
08nnnh
08h = block identifier
0nnnh = bit mask of markers states:
– each bit specifies the state of one marker (the lowest bit
defines the state of the first marker, the next bit defines the
state of the next marker, and so on.)
– set bit indicates that the marker is active
– erased bit indicates that the marker is inactive
– number of available markers (maximum 12) and marker
type (block or spot) are defined in the corresponding
parameter block (see
Table B.16)
Table B.29. Reserved block
Word
number
Name
Comment
0
09xxxh
09h = block identifier
0xxxh = any value (bit b11 is zero)
1
0nnnnh
block length in words
2..
reserved
...
0nnnnh
block length in words
...
09xxxh
09h = block identifier
0xxxh = any value (bit b11 is set)
Table B.30. Block of pause marker
Word
number
Name
Comment
0
0A0nnh
0A0h = ID of the first word of the block
0nnh = first (the lowest) byte of the parameter
1
0A1xxh
0A1h = ID of the second word of the block
0xxh = second byte of the parameter
2
0A2yyh
0A0h = ID of the third word of the block
0yyh = third byte of the parameter
3
0A3zzh
0A3h = ID of the forth (last) word of the block
0zzh = forth (last) byte of the parameter – value 0zzyyxxnnh
specifies the duration of the pause in milliseconds
