CHAPTER 9 Cleaning and Maintenance
9-20 Sysmex XE-5000 Instructions for Use
Revised April 2007 EU
Exp. Date: Displays the expiry limit of the current reagent.
Amount: Displays the current remaining volumes of each
reagent.
(For details, see “Chapter 9: 9.15 Remaining
reagent volume function”.)
Registering reagent information (barcode entry)
1. Display the Reagent setting screen.
2. Use the handheld barcode scanner to read the barcode
that is affixed to the outside of the reagent container, and
is marked EAN-128 or Reagent Code.
The cursor moves to the reagent that has been read, and
the display is updated with the read reagent information.
“Replace” automatically appears for reagents with
updated information. These reagents are designated as
replacements.
3. Select “Execute” on the function menu to register the
reagent information and begin reagent aspiration.
Select “Cancel” on the function menu to delete all of the
read information and return to the previous screen.
Information
When scanning or entering expired reagent, an
Expired Reagent message will be displayed as shown
in box, and the information is not updated. Select
“OK” on the function menu of the Expired Reagent
screen to return to the Reagent setting screen.
If the barcode which was read is not a reagent
barcode, a beep sounds, and the entry is rejected.
Note:
Selecting “Replace” on the function menu alternately
designates the reagent as a replacement and
removes the designation.
Next No.1
Replace EPK
DP No.
Num
DP
Xm
C D N R
Manual Replace
<Reagent setting>
Reag Replace Lot No. Exp.Date Amount
1
2
3
4
5
6
7
8
9
EPK
ESE
SLS
FBA
FFD
FFS
SIM
SNR
RED
A0029
ZA0005
ZA0006
ZA0007
ZA0008
ZA0009
ZA0011
ZA0015
ZA0016
2001/10/06
2001/11/10
2001/12/10
2001/11/15
2001/11/09
2001/12/23
2001/11/11
2001/11/01
2001/11/20
18L
4.6L
5.0L
5.0L
5.0L
42mL
5.0L
3.6L
1.0L
Replace
Manual
Not Ready
Execute Cancel
Next No.1
DP No.
Num
DP
Xm
C D N R
<EPK>
Manual
Not Ready Replace EPK
OK
This reagent has expired
Exp. Date:2001/11/11
<EPK>
