CHAPTER 10 Troubleshooting
Sysmex XE-5000 Instructions for Use 10-31
Revised June 2008
PMT(SSC): Indicates photomultiplier tube voltage of
lateral scattered light channel.
PMT(SFL): Indicates photomultiplier tube voltage of
lateral fluorescence channel.
HGB: Indicates HGB convert value.
2. Sensor 2
The Sensor 2 screen displays the status of the sensor and
solenoid valve.
1. From the Main Menu screen on the Main Unit, select
“Test” on the function menu.
The Test Menu screen will appear.
2. Select “Status” on the function menu of the Test Menu
screen.
The Status screen will appear .
3. Select “Sensor 2” on the function menu of the Status
screen.
The Sensor 2 screen will appear.
Display On and OFF of the Sensor No. 1 to Sensor No.
48.
When the sensor is ON, the No. of the sensor is displayed
highlighted.
3. Counter
This program displays the operation cycle of each unit
(oscillation time for the laser) and the counter of the operation
cycle.
After completion of the piercer replacement or the sample
rotor valve (SRV) cleaning, reset the operation cycle by the
procedure described following.
1. From the Main Menu screen on the Main Unit, select
“Test” on the function menu.
The Test Menu screen will appear.
2. Select “Status” on the function menu of the Test Menu
screen.
The Status screen will appear .
3. Select “Counter” on the function menu of the Status
screen.
The Counter screen will appear.
Next No.123456789012346
DP No. 123456789012345
1 11 21 31 41
2 12 22 32 42
3 13 23 33 43
4 14 24 34 44
5 15 25 35 45
6 16 26 36 46
7 17 27 37 47
8 18 28 38 48
9 19 29 39
10 20 30 40
C D N R
Manual
Not Ready
<Sensor 2>
Cancel
Num
DP
Xm
Next No.123456789012346
DP No. 123456789012345
Num
DP
Xm
TOTAL 3668
CBC 2467
DIFF 2076
NRBC 1643
RET 1528
HPC 20
FFS 1887
SHUT 99
PIAS 1619
SRV 274
FCM-MT 11131
RBC-MT 4706
WB-MT 7234
LASER 43:26
BF-MEAS 18 BF-BCHK 31
C D N R
OK Cancel
Not Ready
Selected counter will be cleared. OK?
<Counter>
Manual
