CHAPTER 10 Troubleshooting
Sysmex XE-5000 Instructions for Use 10-35
Revised April 2007
5. Select “Execute” on the function menu of the Sampler
Test screen. Rack feed-out operation will start. Check the
sampler operation.
6. To cancel the sampler test, select “Cancel” on the
function menu, or press the RETURN key.
CP Unit
Select this program to execute test operation of the CP (cap
piercing) unit. Execute this test when one of the following
messages is displayed and sampler analysis cannot be
performed: “Tube Inv. Position ERR”, “Hand Init Position
ERR”, “Hand Move Position ERR”, “Hand Upper Position
ERR”, “Hand Lower Position ERR” and “Tube Clamp ERR”. If
the test is normally completed, sampler analysis can be
performed.
1. From the Main Menu screen on the Main Unit, select
“TEST” on the function menu.
The Test Menu screen will appear.
2. Select “CP Unit” on the function menu of the Test Menu
screen, then select “Execute”.
After the CP operation, the hand will return to the initial
position.
3. To cancel the CP operation test, select “Cancel” on the
function menu, or press the RETURN key.
Barcode
Select this program to test the ID read function.
1. Place the barcoded tubes in a sampler analysis line.
2. From the Main Menu screen on the Main Unit, select
“TEST” on the function menu.
The Test Menu screen will appear.
3. Select “Barcode” on the function menu of the Test Menu
screen.
The Barcode Test screen will appear.
4. Select “Start” on the function menu of the Barcode Test
screen to start ID reading. The sample ID numbers read
are displayed on the Barcode Test screen.
Barcode on all positions within the rack is read.
The check digit will appear on the CD column.
When reading error occurs, “E” will appear on the FL
column.
The barcode type will appear on the Label column.
(NW7, ITF, JAN, CODE39 or CODE128)
5. To cancel the ID reading test, select “Cancel” on the
function menu, or press the RETURN key.
Start Cancel
Next No.123456789012346
DP No. 123456789012345
ID Read Error
Mainte
101101
CD 1
FL
Label
Code39
CODE128
ITF
NW7
CODE39
JAN
NW7
NW7
NW7
NW7
NW7
E
E
01
02
03
04
05
06
07
08
09
10
[QC-12345678 ]
[123-2001-100000]1
[123-2001-100000]2
[123-2001-100000]3
[123-2001-100000]4
[123-2001-100000]5
[123-2001-100000]6
[123-2001-100000]7
[123-2001-100000]8
[123-2001-100001]9
C D N R
Not Ready
Rack
Tube
Read ID CD FL Label
Num
DP
Xm
