CHAPTER 3 Design and Function
3-10 Sysmex XE-5000 Instructions for Use
Revised April 2007 EU
Panel Keypad LCD
1 Displays the mode to be used next.
There are the following four kinds of modes.
• Manual mode (Normal mode: Displayed as “Manual”)
(HPC analysis mode: Displayed as “HPC Manual”)
(Body fluid analysis mode: Displayed as “BF Manual”)
• Capillary mode (displayed as “Capillary”)
• Sampler mode (displayed as “Sampler”)
• Manual closed mode (displayed as “Closed”)
2 Displays the discrete setting for next analysis.
There are the following five kinds of discrete settings.
• CBC (displayed as “C”)
• CBC+NRBC (displayed as “C N”)
• CBC+RET (displayed as “C R”)
• CBC+DIFF+NRBC (displayed as “CDN”)
• CBC+DIFF+NRBC+RET (displayed as “CDNR”)
3 Displays the status of the Main Unit.
Any of the following status is displayed.
• Ready
• Not Ready
• Running
• S-Ready
•Stat
• S-Not Ready
4 Displays the manual sample ID No. to be analyzed next.
5 Displays the sample ID No. for DP printing.
6 Displays the present error content which has the highest priority.
When the error under the display is reset, the error with the next highest priority is
displayed.
If several errors occur, press the HELP key, and select Error List from the function
menu. All the errors are displayed.
1
2
3
10 10 10 10
4
5
6
7
8
9
To Next Page
