xvi
The printer weighs 34.9 kg (77 lbs) fully assembled, therefore make sure that at
least two people carry it.
To lift the printer, face the front and back of the printer and, with both hands, grip
the recessed areas at the bottom left and right. Never try to lift the printer by grip-
ping any other areas. Lifting the printer by gripping other areas can cause the
printer to fall, resulting in injury.
When lifting the printer, get a firm footing and bend your knees to avoid possible
injuries to your back.
The machine has ventilation holes on the left, right, and rear sides. Ensure that the
machine is installed with a minimum clearance of 150 mm from the right side, 100
mm from the left side, and 200 mm from the rear side. A poorly ventilated machine
can cause excessive internal heat and fire. The accompanying diagram shows the
minimum clearances required for normal operation, consumables replacement,
and maintenance to ensure your machine operates at peak performance.
When moving the printer, be sure to unplug the power cord from the outlet. If the
printer is moved with the power cord connected, it can cause damage to the cord,
which could result in fire or electric shocks.
Recess
If you hold the printer by the front door,
left or right sides, there is a danger of
the printer falling.
100mm
200mm
150mm
600mm
