8.2 Replacing the Drum Cartridge

187

Daily Care

8

8.2.2 Replacing the Drum Cartridge

Follow the procedure below to replace the drum cartridge.

Push up button ‘A’ ➀ and fully open the

front cover ➁.

Open the paper outlet cover.
