LSR64 ACC:P,#1..16
6-142
LSR64 ACC:P,#1..16 64-Bit Logical Shift Right
SYNTAX OPTIONS OPCODE OBJMODE RPT CYC
LSR64 ACC:P,#1..16 0101 0110 1001 SHFT 1 − 1
Operands ACC:P Accumulator register (ACC) and product register (P)
#1..16 Shift value
Description Logical shift right the 64-bit combined value of the ACC:P registers by the
amount specified in the shift value field. As the value is shifted, the most
significant bits are zero filled and the last bit shifted out is stored in the carry
bit flag:
0
C
ACC:P
ACC:P
Right shift
(Immediate value)
Discard
other bits
Last bit out
Flags and
Modes
N After the shift, if bit 31 of the ACC register is 1 then ACC:P is negative and the
N bit is set; otherwise N is cleared.
Z After the shift, the Z flag is set if the combined 64-bit value of the ACC:P is
zero; otherwise, Z is cleared.
C The last bit shifted out of the combined 64-bit value is loaded into the C bit.
Repeat This instruction is not repeatable. If this instruction follows the RPT
instruction, it resets the repeat counter (RPTC) and executes only once.
Example
; Logical shift right the 64-bit Var64 by 10:
MOVL ACC,@Var64+2 ; Load ACC with high 32 bits of Var64
MOVL P,@Var64+0 ; Load P with low 32 bits of Var64
LSR64 ACC:P,#10 ; Logical shift right ACC:P by 10
MOVL @Var64+2,ACC ; Store high 32-bit result into Var64
MOVL @Var64+0,P ; Store low 32-bit result into Var64
