Lab 6: Analog-to-Digital Converter
6 - 32 TMS320F2837xD Microcontroller Workshop - Analog Subsystem
Acquisition Buffer Size 50
DSP Data Type 16-bit unsigned integer
Sampling Rate (Hz) 50000
Start Address AdcBuf
Display Data Size 50
Time Display Unit
µs
Select OK to save the graph options.
14. Recall that the code toggled the GPIO18 pin alternately high and low. (Also, the ADC
ISR is toggling the LED D9 on the LaunchPad as a visual indication that the ISR is
running). If you had an oscilloscope available to display GPIO18, you would expect to
see a square-wave. Why does Code Composer Studio plot resemble a triangle wave?
What is the signal processing term for what is happening here?
15. Recall that the program toggled the GPIO18 pin at a 50 kHz rate. Therefore, a complete
cycle (toggle high, then toggle low) occurs at half this rate, or 25 kHz. We therefore
expect the period of the waveform to be 40 µs. Confirm this by measuring the period of
the triangle wave using the “measurement marker mode” graph feature. In the graph
window toolbar, left-click on the ruler icon with the red arrow. Note when you hover your
mouse over the icon, it will show “
Toggle Measurement Marker Mode”. Move
the mouse to the first measurement position and left-click. Again, left-click on the
Toggle Measurement Marker Mode icon. Move the mouse to the second
measurement position and left-click. The graph will automatically calculate the difference
between the two values taken over a complete waveform period. When done, clear the
measurement points by right-clicking on the graph and select
Remove All
Measurement Marks
(or Ctrl+Alt+M).
Using Real-time Emulation
Real-time emulation is a special emulation feature that offers two valuable capabilities:
A. Windows within Code Composer Studio can be updated at up to a 10 Hz rate while the
MCU is running. This not only allows graphs and watch windows to update, but also
allows the user to change values in watch or memory windows, and have those
changes affect the MCU behavior. This is very useful when tuning control law
parameters on-the-fly, for example.
B. It allows the user to halt the MCU and step through foreground tasks, while specified
interrupts continue to get serviced in the background. This is useful when debugging
portions of a real-time system (e.g., serial port receive code) while keeping critical
parts of your system operating (e.g., commutation and current loops in motor control).
We will only be utilizing capability “A” above during the workshop. Capability “B” is a
particularly advanced feature, and will not be covered in the workshop.
16. The memory and graph windows displaying AdcBuf should still be open. The jumper wire
between ADCINA0 (header J3, pin #30) and GPIO18 (header J1, pin #4) should still be
connected. In real-time mode, we will have our window continuously refresh at the
default rate. To view the refresh rate click:
