F28379D Experimenter Kit
A - 4 TMS320F2837xD Microcontroller Workshop – Appendix A
controlCARD and LaunchPad LED Mapping
Function controlCARD LaunchPad
LED – Power LED LD1 (green) LED D1 (green)
LED – GPIO31 LED LD2 (red) LED D10 (blue)
LED – GPIO34 LED LD3 (red) LED D9 (red)
Stand-Alone Operation (No Emulator)
When the device is in stand-alone boot mode, the state of GPIO72 and GPIO84 pins are used to
determine the boot mode. On the controlCARD switch SW1 controls the boot options for the
F28379D device. Check that switch SW1 positions 1 and 2 are set to the default “1 – on” position
(both switches up). This will configure the device (in stand-alone boot mode) to GetMode. Since
the OTP_KEY has not been programmed, the default GetMode will be boot from flash. Details of
the switch positions can be found in the controlCARD information guide.
