TMS320F2837xD Microcontroller Workshop
TMS320F2837xD Microcontroller Workshop - Introduction v
F28379D controlCARD
SW1: Boot
Modes
TMS320F28379D
A:J1 - USB
emulation/
UART
J8: Host/
Device
XDS100v2 emulation
and isolation circuitry
A:SW1 - isolated emulation
and UART communication
enable switch
U5: µSD
card
LED LD2:
GPIO31 (red)
LED LD3:
GPIO34 (red)
LED
LD1:
Power
(green)
J2 - J7: USB
PHY connection
enable jumpers
SW2: ADC
VREFHI
ADC A & B
SW3: ADC
VREFHI
ADC C & D
Note: F28379D – 337 BGA
controlCARD Docking Station
