2-8 4262930-Rev A
SPECIFICATIONS AND GENERAL INFORMATION
2
Engine
Electrical
Power Train
Brakes
Repair Specifications
Engine Mounting Carriage Bolt Torque lb-ft (N·m) 13 (17.7)
Test and Adjustment Specifications
Ceramic Resistor Resistance at 68° F ohms 5 ± 5%
120 Ohm Resistor Connector Resistance at 68° F
ohms 120 ± 10%
Throttle Potentiometer Low End Resistance at 68° F
ohms 18.9–35.1
Throttle Potentiometer High End Resistance at 68° F
ohms 3710–6890
Bail Potentiometer Resistance at 68° F
ohms 3640–6760
Repair Specifications
Battery Pack Fuse Nut Torque lb-in. (N·m) 25 (2.82)
Generator Engine Shaft Screw Torque
lb-ft (N·m) 20.4 (27.7)
Generator Mounting Screw Torque
lb-in. (N·m) 68 (7.7)
Generator Adapter Plate Mounting Screw Torque
lb-ft (N·m) 14.4 (9.5)
Generator Cover Mounting Screw Torque
lb-in. (N·m) 68 (7.7)
Check and Adjustment Specifications
Traction (Transfer) Drive Belt Maximum Deflection
with 3.5–6.3 lb (15.6–28.0 N) of Force Applied at the
Midpoint Between Pulleys.
in. (mm) 0.14 (3.5)
Traction (Final) Drive Belt Maximum Deflection with
12.5–15.2 lb (55.6–67.6 N) of Force Applied at the
Midpoint Between Pulleys.
in. (mm) 0.10 (2.5)
Repair Specifications
Park Brake Lever Actuating Force lb (kg) 10 (4.5)
Park Brake Band—Anchor Pin Center-to-Center
Distance
(Park Brake Released)
in. (mm) 1.50 (38)
