SPECIFICATIONS AND GENERAL INFORMATION
4262930-Rev A 2-9
2
Cutting Unit
Accessories
Check and Adjustment Specifications
Bedknife-to-Reel Gap in. (mm) 0.001–0.003 (0.025–0.075)
Reel Bearing Pre-Load
in. (mm) 0.040 (1.0)
Bedknife Front Face Height (minimum)
in. (mm) 0.035 (0.9)
Bedknife Front Face Angle (all bedknives)
degrees 5
Bedknife Top Face Angle (rear relief) (all bedknives
except Super Tournament)
degrees 8–10
Super Tournament Bedknife Top Face Angle
(rear relief)
degrees 5–7
Reel Blade Relief Angle
degrees 45
Check and Adjustment Specifications
Turf Groomer Eccentric Mounting Screw Torque lb-ft (N·m) 8–10 (10.8–13.6)
Turf Groomer Belt Tension Link Mounting Screw Torque
lb-ft (N·m) 20 (27.1)
Repair Specifications
Solid Front Roller Assembly Maximum Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Solid Tube Front Roller Lock Nut Torque
lb-ft (N·m) 10–30 (13.5–40.6)
Solid Tube Front Roller Shaft-to-Bearing Rotational
Resistance
lb-in. (N·m) 0–1 (0–0.11) with No End Play
Solid Tube Front Roller Assembly Maximum Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Front Roller Lock Nut Torque
lb-ft (N·m) 10–30 (13.5–40.6)
Grooved Front Roller Shaft-to-Bearing Rotational
Resistance
lb-in. (N·m) 0–1 (0–0.11) with No End Play
Grooved Front Roller Assembly Rotational Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Disc Roller Assembly Maximum Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Grooved Segmented Front Roller Jam Nut Torque
lb-ft (N·m) 70 (95)
Grooved Segmented Front Roller Assembly Rotational
Resistance
lb-in. (N·m) 6 (0.68) Maximum with No End Play
Push Broom Assembly Rod-To-Cam Gap
in. (mm) 0.25 (6.3)
