5-4 4203780 First Edition
HYDROSTATIC POWER TRAIN
5
Portable In-Line Filter
See Figure 5-1.
Figure 5-1
When hydraulic components fail internally, debris from
the failed component can spread throughout the
hydraulic system, causing additional damage.
This situation can be magnified when dealing with a
closed loop traction system where oil is not filtered. In the
event of a traction system component failure, It is
recommended that all traction system components be
disassembled and cleaned, or filtered using a portable
in-line filter available through your Jacobsen Dealer. The
portable in-line filter should also be used when testing
hydraulic systems or after replacing a failed component.
IMPORTANT
Always install the in-line filter so oil flows through
the filter before entering a component. Once filtering
has begun, never reverse the flow of oil, or debris will
re-enter the system.
TN1367
