3-2 4203780 First Edition
ENGINE
3
Specifications
General Engine Specifications
Repair Specifications
Engine
Manufacturer/Model Kubota
®
Tier 2/V2203-DI-B
Engine Type 4-stroke, diesel
Fuel Requirement No. 2-D diesel fuel (Cetane Rating-45)
Number of Cylinders/Configuration 4, in-line
Displacement
cu in. (cc) 131.1 (2148)
Bore x Stroke
in. (mm) 3.43 x 3.64 (87 x 92.4)
Power Output
hp (kW) 49 (36.5) @ 2500 rpm
Firing Order 1-3-4-2
Compression Ratio 19:1
Injection Timing (Before T.D.C.) 18°
Cooling System liquid cooled
Cooling System Capacity
qt (L) 8 (7.6)
Idle Speed 850–900 rpm
Maximum Speed (No Load) 3050 rpm
Oil Sump Capacity
qt (L) 10 (9.5)
Alternator 12 volt, 45 amp
Dry Weight
lb (kg) 397 (180)
Specification
Hydrostatic Pump Drive Plate Screw lb-ft (N·m) 37 (51)
To Next Page
