7-2 4203780 First Edition
STEERING
7
Specifications
Test and Adjustment Specifications
Steering System Leakage Test—
Cylinder Leakage
pt (L) Zero—Nominal Amount
Rear Axle Alignment Toe-In
Measurement
in. (mm) 0.0625 (1.6)
Rear Axle Spindle Arm-to-Axle Stop
Measurement
in. (mm) 0.030—0.060 (0.76—1.5)
Repair Specifications
Steering Wheel Nut lb-ft (N·m) 28—30 (38—41)
Steering Valve Rotor-to-Stator
Clearance
in. (mm) 0.003 (0.08)
Steering Valve Metering Assembly
Screw Torque
lb-in. (N·m) 11—13 (1.2—1.5)
Steering Valve Port Cover-to-Port
Manifold Nut Torque
lb-ft (N·m) 18—22 (24—30)
Steering Cylinder Ball Joint-to-
Steering Arm Torque
lb-ft (N·m) 40 (54)
Tie Rod Ball Joint-to-Steering Arm
Torque
lb-ft (N·m) 30 (41)
